51.2V Low voltage battery | ePowerCUBE BALV

ePowerCUBE BALV Series

LOW-VOLTAGE
Residential Battery Pack

AES5.1-L (Heating)/AES5.1-L1

More Than 6000 Full Charge and Discharge

ePowerCUBE BALV is manufactured by safer LiFePO4 material, which is able to withstand 6,000 full charge/discharge cycles and 90% DoD

75kWh Super Large Capacity

ePowerCUBE BALV supports 30kWh capacity in a single cluster (1PCS+1BCU+6PACK) and 75kWh maximum capacity in an integrated system

The ePowerCUBE BALV features an intelligent remote monitoring system for real-time tracking of battery health, SOC, and energy flow via a mobile app or web portal

10 Years Battery Warranty

ePowerCUBE BALV uses an industrial design with IP65 protection, which maximizes battery performance and enables a 10-year warranty

The integrated low-temperature self-heating mechanism ensures efficient charging and discharging in extreme cold, preventing lithium plating and extending battery life during winter.

Technical Specifications

Low-Voltage (LV) Residential Battery Pack

Rated Voltage (V)	51.2
Rated Capacity (Ah)	100
Modular Capacity (kWh)	5.12
Maximum Charge/Discharge Current	100A/100A (25°C)
Cycle Life	10,000+ cycles
Operating Temperature Range	-25°C ~ 60°C (With heating function)
Battery Type	LFP (16S1P)
Weight (kg)	48
Scalability	Supports up to 36 battery packs
Certifications	IEC 61000-6-1, IEC 61000-6-3, IEC 62619, IEC 63056, IEC 60730 Annex H
